10 Wheels 25 Ton Tipper Truck

Trailer Parameters

Truck Model ZZ3257N3647A (LHD)
Dimension(Lx W xH)(unloaded)(mm) 8214x2496x3386
Cargo body size (L*W*H, mm(mm) 5400*2300*1200
Cargo body thickness(mm) bottom:8mm, side:6mm,
Lift type of Carriage Ventral lifting
Approaching angle/Departure angle(°)  19/26
Overhang(front/rear) (mm) 1500/1739
Wheel base (mm) 3625+1350
Max speed(km/h) 75
Curb weight(kg) 12290
Loading Weight(kg) 30000
Fuel tanker capacity (L) 300L with locking fuel cap
Fuel consumption(L/100km) 32
Clutch Single-plate dry clutch Φ420mm
Engine Model
(Steyr technology, made in China)
Model WD615.47,4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , turbo-charging and intercooling
Horse Power, max(kw/rpm) 371HP,247/2200
Emission Standard EUROII
Transmission Model HW 19710,10 forwards and 2 reverse
Brake system Service brake Dual circuit compressed air brake
Parking brake spring energy, compressed air operating on rear wheels
Auxiliary brake Engine exhaust brake
Steering system Model ZW8118 hydraulic steering with power assistance
Front axle HF9 , Steering with double T-cross section beam
Loading capacity:9000KG
Rear axle HC16, Casting axle housing, central double reduction with differential locks between axles and wheels
Color Red
Tire 12.00R20 tubelee tyre  11 pieces
Electrical system Operating voltage 24V,negative grounded
Starter 24V,7.35KW
Alternator 28V,1500W
Batteries 2*12V.165Ah
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light.
Cab HW76 cabin
